Smart Home Gigabit Gateway W20

    •        4100XQ.png

      Main functions :
      2.4G wifi coverage, Gigabit routing coverage
      DC power supply
      Home intelligent gateway; control smart home terminal
      Reduce Co-Channel Interference RF optimizationSmart Broadcast optimization
      Support multi-SSID4LAN portsIndoor Placed
      Supoort PPPOE dial-up InternetSupport 60 concurrent users
      RF protection module
      Support high gain antenna
      Custom SSID&ENctrytionSupport indoor scene
      The main selling points :
      Home core gateway;Control smart home terminals
      Support 60 concurrent users wifi hotspot
      4 external high gain antenna
      APP Control; manager the usersSupport big data analysis; remote maintenance
      Support Portal,multi-SSID management





Scheme & Case

Technical specifications



Chipset

 MT7621+MT7612


Frequency2.4G+5.8G

Users

≥60

Speed

1000Mbps
Wifi protocal

IEEE802.11n/802.11g/802.11b/802.3/802.3u
ROM /RAM

128M/16M
Software

Remote cloud platform management
Power         DC12V 1A

Ports

4 gigabit LAN,1 gigabit WAN
LED

power/WLAN/WAN/LAN1/LNA2/LNA3/LNA4
Antenna         4 *Omnidirectional high frequency antennas
Config upgrade          Support local, platform firmware upgrade, configuration upgrade
Software upgrade


Support local patch upgrade
